Blade
|
Art.
|
Length |
Length
of cutting edge |
Total
length |
typical applications
|
|
E12
|
220012
|
2
|
12 mm
|
25 mm
|
universal blade for various materials as cardboard, gasket material, foam rubber, cork
|
|
E18
|
220025
|
1
|
13,5 mm
|
26,5 mm
|
universal blade for various materials as cardboard, gasket material, foam rubber, cork
|
|
E25
|
220025
|
1
|
25 mm
|
39 mm
|
universal blade for various materials as cardboard, gasket material, foam rubber, cork
|
|
E28
|
220028
|
1
|
30 mm
|
45 mm
|
universal blade for various materials as cardboard, gasket material, foam rubber, cork
|
|
E30
|
220030
|
1
|
2,5 mm
|
25 mm
|
special blade für TCM module; wedge blade 30 degrees for normal foils and writings
|
|
E50
|
220050
|
1
|
3,5 mm
|
25 mm
|
special blade für TCM module; wedge blade 50 degrees for flock textile foils,felt, cardboard
|
|
E70
|
220070
|
1
|
8 mm
|
25 mm
|
special blade für TCM module; wedge blade 50 degrees for flock textile foils,felt, cardboard
|
|
E85
|
220085
|
1
|
50 mm
|
65 mm
|
special blade for EOT module; e.g. for soft polyurethane foam panels
|
|
E87
|
220087
|
1
|
70 mm
|
83 mm
|
special blade for EOT module; e.g. for soft polyurethane foam panels
|
|
E92
|
220092
|
1
|
120 mm
|
133 mm
|
special blade for EOT module; e.g. for soft polyurethane foam panels
|
|
W38
|
220100
|
1
|
35 mm
|
50 mm
|
special blade for EOT module with wave cut geometry; e.g. for soft polyurethane foam panels
|
|
W60
|
220110
|
1
|
58 mm
|
73 mm
|
special blade for EOT module with wave cut geometry; e.g. for soft polyurethane foam panels
|
