Choosing the Right Blade:
Material Type: Select blades based on the material you are cutting (e.g., vinyl, fabric, cardboard).
Cutting Depth and Angle: Ensure the blade's cutting depth and angle are suitable for your material.
Blade Type: Decide between drag, oscillating, or rotary blades based on your cutting needs.
|
Blade Model |
Cutting Angle |
Maximum Cutting Depth |
Suitable Materials |
Compatibility |
|
Z10 |
50° |
4.8 mm |
Reflective vinyl, PVC, textiles |
Zund S3, G3, L3 |
|
Z11 |
55° |
7.8 mm |
Woven materials, leather |
Zund S3, G3, L3 |
|
Z12 |
80° |
13.2 mm |
Textiles, cardboard |
Zund S3, G3, L3 |
|
Z13 |
81.5° |
16.5 mm |
Tough materials like rubber and leather |
Zund S3, G3, L3 |
|
Z44 |
60° |
14 mm |
Corrugated cardboard and foam |
Zund S3, G3 |
|
Z45 |
84° |
17.2 mm |
Cardboard, foam |
Zund S3, G3 |
|
Z46 |
84° |
14.3 mm |
Various flexible materials |
Zund S3, G3 |
-
Zund S3 Z10 Double Edged Carbide Drag knife Blade 50° Cutting Angle for Reflective Vinyl-3910301
-
Zund S3 Z11 Carbide Drag Knife Blade 60° Cutting Angle for Hard Materials 3910309
-
Zund Z12 Tungsten Carbide Drag Knife blade,flat-stock 3910320
-
Zund Z13 Tungsten Carbide Drag Knife blade,flat-stock 3910321
