Specifications:
Blade Angle: 54°
Blade Length: 25.00 mm
Blade Width: 5.60 mm
Thickness: 0.63 mm
Maximum Cutting Depth: 7.40 mm
Material: Premium grade tungsten carbide
Hardness: HRC 91
Compatible Materials:
Folding Carton (100 - 1500g)
Gasket Materials
Foam
Leather (hard, hide, suede)
Canvas
Mesh
Polyester Fabric
Reflective Vinyl Film
Self-adhesive Vinyl Film
Magnetic Foil
Paper (100 - 400g)
PVC Banner
Corrugated Cardboard (single wall)
Soft Board
Composite Materials
Flexible Films
Vinyls
These specifications ensure the ZUND Z16 blade's adaptability across various applications, making it a reliable choice for cutting diverse materials with precision.
