The Aristo System blades 7265, 7267, and 7275 are carbide plotter knife blades used in cutting plotters or flatbed cutters typically for vinyl, cardboard, textiles, and other materials. These numbers refer to specific blade types that differ based on cutting angle, blade geometry, and material application.
Here's a breakdown of their typical differences:
Aristo 7265·
Angle: 45·
Use Case: General-purpose blad
Material Cut: Vinyl, film, light cardboard
Notes: Most commonly used for standard media. Balanced between precision and durability.
Aristo 7267·
Angle: 60°·
Use Case: For thicker or tougher materials
Material Cut: Sandblast stencil, thick vinyl, laminated materials
Notes: Sharper angle for deeper cuts. More prone to wear than 45°, but necessary for tougher jobs.·
Aristo 7275·
Angle: 30°·
Use Case: Precision cuttin·
Material Cut: Thin films, paper, very fine details
Notes: Best for detailed designs and delicate materials. Less blade penetration depth.·
Summary Table
|
Blade No. |
Angle |
Best For |
Cuts |
|
45° |
General-purpose |
Vinyl, film |
|
|
60° |
Tough/thicker materials |
Thick vinyl, stencil |
|
|
30° |
Fine detail, thin material |
Film, paper |
