Here are the specifications and differences for the Multicam 003612-MC50, 003612-MC51, and 003612-MC52 rotary decagonal (10-sided) knife blades:
Blade Specifications & Differences
| Model | Diameter | Bore | Thickness | Max Cut Depth | DRT Holder |
|
|---|---|---|---|---|---|---|
| 003612-MC50 (K1) | 25mm | 8mm | 0.6mm | 3.5mm | DRT1 |
|
| 003612-MC51 (K2) | 28mm | 8mm | 0.6mm | 5mm | DRT2 |
|
| 003612-MC52 (K3) | 32mm | 8mm | 0.6mm | 7mm | DRT3 |
|
All three blades share a 0.6mm thickness and an 8mm bore, ensuring compatibility with their respective DRT holders. The primary differences lie in their diameters and maximum cutting depths, which determine their suitability for various materials and cutting requirements.
Compatibility & Alternatives
These blades are compatible with MultiCam's DRT systems:
-
003612-MC50 (K1): Fits DRT1 holder.
-
003612-MC51 (K2): Fits DRT2 holder.
-
003612-MC52 (K3): Fits DRT3 holder.
Key Differences
- Knife Height Increases progressively from MC50 (25.0 mm) to MC52 (32.0 mm), allowing for deeper material engagemen.
- Max Cutting Depth MC50 and MC51 support up to 5.0 mm, while MC52 offers a deeper cut of up to 7.0 m.
- etween depth and precisio.
- MC52 Best for thicker materials or applications needing deeper
Summary
003612-MC50 (K1): 25mm diameter, 3.5mm cut depth, DRT1 holder.
003612-MC51 (K2): 28mm diameter, 5mm cut depth, DRT2 holder.
003612-MC52 (K3): 32mm diameter, 7mm cut depth, DRT3 holder.
Compatibilit
These blades are compatible with various cutting systems, includig:
- Summa
- Zünd
- Gerber
- iEcho
- Blackman & White
- Colex
- Bullmer
-Esko/Kongsberg
If you need assistance selecting the appropriate blade for your specific application or material, feel free to ask!
